    Best posts made by nasheayahu

    • RE: XCP-ng - mount.nfs: access denied by server while mounting

      @olivierlambert said in XCP-ng - mount.nfs: access denied by server while mounting:

      Can you show the incorrect and the correct config used to make it even more clear?

      openSUSE 15.4 NFS Setup:

      Permission for /run/media/XCP-ng/WebServer/Production (Note: this is a mounted internal HD)

      drwxrwxr-x 2 root nobody 4096 Jul 22 21:38 Production


      Folder settings in /etc/export

      /run/media/XCP-ng/WebServer/Production 10.60.70.0/24(rw,root_squash,sync,no_subtree_check) 10.70.70.0/24(rw,root_squash,sync,no_subtree_check)


      To make sure the proper NFS RPC-based services are enabled for rpcbind, use the following

      command: sudo rpcinfo -p
         program vers proto   port  service
          100000    4   tcp    111  portmapper
          100000    3   tcp    111  portmapper
          100000    2   tcp    111  portmapper
          100000    4   udp    111  portmapper
          100000    3   udp    111  portmapper
          100000    2   udp    111  portmapper
          100024    1   udp  55952  status
          100024    1   tcp  43101  status
          100005    1   udp  20048  mountd
          100005    1   tcp  20048  mountd
          100005    2   udp  20048  mountd
          100005    2   tcp  20048  mountd
          100005    3   udp  20048  mountd
          100005    3   tcp  20048  mountd
          100003    3   tcp   2049  nfs
          100227    3   tcp   2049  nfs_acl
          100003    3   udp   2049  nfs
          100227    3   udp   2049  nfs_acl
          100021    1   udp  57533  nlockmgr
          100021    3   udp  57533  nlockmgr
          100021    4   udp  57533  nlockmgr
          100021    1   tcp  39073  nlockmgr
          100021    3   tcp  39073  nlockmgr
          100021    4   tcp  39073  nlockmgr


      If one of the NFS services does not start up correctly, rpcbind will be unable to map RPC requests from clients for that service to the correct port.

      To allow clients to access NFS shares behind a firewall, configure the firewall by running the following commands on the NFS server:

      firewall-cmd --permanent --add-service mountd
      firewall-cmd --permanent --add-service rpc-bind
      firewall-cmd --permanent --add-service nfs
      firewall-cmd --permanent --add-port=<mountd-port>/tcp
      firewall-cmd --permanent --add-port=<mountd-port>/udp
      firewall-cmd --reload


      Note: I used firewall-config to do the port settings.

      XCP-ng / Remote Settings:

      New file system remote
      Type

      • NFS
      • Backup Production Wev Servers
      • ..
      • 10.60.70.15
      • leave port empty
      • /run/media/XCP-ng/WebServer/Production
      • ..

      Note: Make sure you can do this on both systems

      [19:48 xcp-pro ~]# showmount --exports 10.60.70.15
      Export list for 10.60.70.15:
      ..
      ...
      /run/media/XCP-ng/WebServer/Production  10.70.70.0/24,10.60.70.0/24
      ...
      ..
      .


      @olivierlambert said in XCP-ng - mount.nfs: access denied by server while mounting:

      Thanks for the feedback!

      For sure, anytime to help make XCP-ng the best! 👍

      posted in Xen Orchestra
      N
      nasheayahu
    • RE: XOA Console: Windows server - sending ctl+alt+delete keys

      Cancel that! I found the keys icon for sending the combo just above console.....

      posted in Xen Orchestra
      N
      nasheayahu

    Latest posts made by nasheayahu

    • RE: XCP-ng - mount.nfs: access denied by server while mounting

      @olivierlambert said in XCP-ng - mount.nfs: access denied by server while mounting:

      Can you show the incorrect and the correct config used to make it even more clear?

      openSUSE 15.4 NFS Setup:

      Permission for /run/media/XCP-ng/WebServer/Production (Note: this is a mounted internal HD)

      drwxrwxr-x 2 root nobody 4096 Jul 22 21:38 Production


      Folder settings in /etc/export

      /run/media/XCP-ng/WebServer/Production 10.60.70.0/24(rw,root_squash,sync,no_subtree_check) 10.70.70.0/24(rw,root_squash,sync,no_subtree_check)


      To make sure the proper NFS RPC-based services are enabled for rpcbind, use the following

      command: sudo rpcinfo -p
         program vers proto   port  service
          100000    4   tcp    111  portmapper
          100000    3   tcp    111  portmapper
          100000    2   tcp    111  portmapper
          100000    4   udp    111  portmapper
          100000    3   udp    111  portmapper
          100000    2   udp    111  portmapper
          100024    1   udp  55952  status
          100024    1   tcp  43101  status
          100005    1   udp  20048  mountd
          100005    1   tcp  20048  mountd
          100005    2   udp  20048  mountd
          100005    2   tcp  20048  mountd
          100005    3   udp  20048  mountd
          100005    3   tcp  20048  mountd
          100003    3   tcp   2049  nfs
          100227    3   tcp   2049  nfs_acl
          100003    3   udp   2049  nfs
          100227    3   udp   2049  nfs_acl
          100021    1   udp  57533  nlockmgr
          100021    3   udp  57533  nlockmgr
          100021    4   udp  57533  nlockmgr
          100021    1   tcp  39073  nlockmgr
          100021    3   tcp  39073  nlockmgr
          100021    4   tcp  39073  nlockmgr


      If one of the NFS services does not start up correctly, rpcbind will be unable to map RPC requests from clients for that service to the correct port.

      To allow clients to access NFS shares behind a firewall, configure the firewall by running the following commands on the NFS server:

      firewall-cmd --permanent --add-service mountd
      firewall-cmd --permanent --add-service rpc-bind
      firewall-cmd --permanent --add-service nfs
      firewall-cmd --permanent --add-port=<mountd-port>/tcp
      firewall-cmd --permanent --add-port=<mountd-port>/udp
      firewall-cmd --reload


      Note: I used firewall-config to do the port settings.

      XCP-ng / Remote Settings:

      New file system remote
      Type

      • NFS
      • Backup Production Wev Servers
      • ..
      • 10.60.70.15
      • leave port empty
      • /run/media/XCP-ng/WebServer/Production
      • ..

      Note: Make sure you can do this on both systems

      [19:48 xcp-pro ~]# showmount --exports 10.60.70.15
      Export list for 10.60.70.15:
      ..
      ...
      /run/media/XCP-ng/WebServer/Production  10.70.70.0/24,10.60.70.0/24
      ...
      ..
      .


      @olivierlambert said in XCP-ng - mount.nfs: access denied by server while mounting:

      Thanks for the feedback!

      For sure, anytime to help make XCP-ng the best! 👍

      posted in Xen Orchestra
      N
      nasheayahu
    • XCP-ng - mount.nfs: access denied by server while mounting

      This is a new discovery during the Solved "NFS ISO: Cannot read property 'Export' of undefined" in creating a NFS Remote for backups.

      Since I'm using openSUSE Leap 15.4 as a SR and Backups, I posted on there forum "XCP-ng - mount.nfs: access denied by server while mounting" first to get the solution and it was solved moments later, and to my delight 😀 it was a very simple fix, so I'm posting here just in case anyone else has this problem.

      Leap was denying access for XCP-ng backup test, everything on Leap was configured correctly, but I had to remove the Port number on the XCP-ng Remote setting and now it works. 😌

      posted in Xen Orchestra
      N
      nasheayahu
    • RE: NFS ISO: Cannot read property 'Export' of undefined

      @olivierlambert said in NFS ISO: Cannot read property 'Export' of undefined:

      Let's consider this thread fixed by adding the correct NFS configuration on the server side and create a new one describing your issue.

      👍

      posted in Xen Orchestra
      N
      nasheayahu
    • RE: Manually Mount A HD When Needed From XCP-ng?

      @ravenet said in Manually Mount A HD When Needed From XCP-ng?:

      You can script mount and umount commands as part of jobs or as part of backup jobs.

      👍

      posted in Xen Orchestra
      N
      nasheayahu
    • RE: NFS ISO: Cannot read property 'Export' of undefined

      Hang on, the recent post deals with Settings / Remotes, got off track by watching "Tutorial: Configuring Backups For XCP NG Using Xen Orchestra 2021" but, in doing so the posted change correct the initial problem, so I'm able to create a SR / {VDI, ISO} NFS. 😊

      So now dealing with the Remotes configuration, 😀 I would like to fix this so I can can configure for backups. Do I need to create a new post or can we continue from here?

      posted in Xen Orchestra
      N
      nasheayahu
    • RE: NFS ISO: Cannot read property 'Export' of undefined

      Update: well I have mounts showing in XCP-ng, I needed to add rpc-bind and mountd to Leaps firewall, however I need to fix the permission because its being denied:

      remote.test
      {
        "id": "ed6bc7d7-8e3f-4d01-a57e-a9865a72c8ce"
      }
      {
        "shortMessage": "Command failed with exit code 32: mount -o  -t nfs 10.60.70.45:2049:/run/media/Backup-I/XCP-ng-lab /run/xo-server/mounts/ed6bc7d7-8e3f-4d01-a57e-a9865a72c8ce",
        "command": "mount -o  -t nfs 10.60.70.45:2049:/run/media/Backup-I/XCP-ng-lab /run/xo-server/mounts/ed6bc7d7-8e3f-4d01-a57e-a9865a72c8ce",
        "escapedCommand": "mount -o \"\" -t nfs \"10.60.70.45:2049:/run/media/Backup-I/XCP-ng-lab\" \"/run/xo-server/mounts/ed6bc7d7-8e3f-4d01-a57e-a9865a72c8ce\"",
        "exitCode": 32,
        "stdout": "",
        "stderr": "mount.nfs: access denied by server while mounting 10.60.70.45:2049:/run/media/Backup-I/XCP-ng-lab",
        "failed": true,
        "timedOut": false,
        "isCanceled": false,
        "killed": false,
        "message": "Command failed with exit code 32: mount -o  -t nfs 10.60.70.45:2049:/run/media/Backup-I/XCP-ng-lab /run/xo-server/mounts/ed6bc7d7-8e3f-4d01-a57e-a9865a72c8ce
      mount.nfs: access denied by server while mounting 10.60.70.45:2049:/run/media/Backup-I/XCP-ng-lab",
        "name": "Error",
        "stack": "Error: Command failed with exit code 32: mount -o  -t nfs 10.60.70.45:2049:/run/media/Backup-I/XCP-ng-lab /run/xo-server/mounts/ed6bc7d7-8e3f-4d01-a57e-a9865a72c8ce
      mount.nfs: access denied by server while mounting 10.60.70.45:2049:/run/media/Backup-I/XCP-ng-lab
          at makeError (/opt/xo/xo-builds/xen-orchestra-202207160304/node_modules/execa/lib/error.js:60:11)
          at handlePromise (/opt/xo/xo-builds/xen-orchestra-202207160304/node_modules/execa/index.js:118:26)
          at NfsHandler._sync (/opt/xo/xo-builds/xen-orchestra-202207160304/@xen-orchestra/fs/src/_mount.js:64:7)"
      }


      Folder permission on Leap:

      chown -R nobody: /run/media/Backup-I/XCP-ng-lab/
      chmod -R 777 /run/media/Backup-I/XCP-ng-lab/

      posted in Xen Orchestra
      N
      nasheayahu
    • RE: NFS ISO: Cannot read property 'Export' of undefined

      @olivierlambert said in NFS ISO: Cannot read property 'Export' of undefined:

      showmount --exports <NFS SERVER IP>

      From XCP-ng:

      clnt_create: RPC: Port mapper failure - Unable to receive: errno 113 (No route to host)


      From XCP-ng - AlmaLinux VM:

      clnt_create: RPC: Unable to receive


      From NFS Server on Leap 15.4:

      Export list for 10.60.70.45:
      /home/nasheayahu/Downloads/Iso/Pop!_OS              10.70.70.0/24,10.60.70.0/24
      /home/nasheayahu/Downloads/Iso/RHEL                 10.70.70.0/24,10.60.70.0/24
      /home/nasheayahu/Downloads/Iso/MX-Linux             10.70.70.0/24,10.60.70.0/24
      /home/nasheayahu/Downloads/Iso/AlmaLinux-9.0-x86_64 10.70.70.0/24,10.60.70.0/24

      posted in Xen Orchestra
      N
      nasheayahu
    • RE: NFS ISO: Cannot read property 'Export' of undefined

      Just an update: I am able to get SMB working, but I would like to have NFS ISO as well...

      posted in Xen Orchestra
      N
      nasheayahu
    • NFS ISO: Cannot read property 'Export' of undefined

      Running the latest openSUSE Leap 15.4 as my IT Workstation to manage both my XCO-ng servers, etc,... and my NFS exports file look like this for one of the NFS ISO I'm trying to configure is:

      /home/nasheayahu/Downloads/Iso/RHEL	10.60.70.0/24(ro,root_squash,sync,no_subtree_check) 10.70.70.0/24(ro,root_squash,sync,no_subtree_check)


      and idmapd.conf

      Verbosity = 0
      Pipefs-Directory = /var/lib/nfs/rpc_pipefs
      Domain = kohanyim.com

      [Mapping]

      Nobody-User = nobody
      Nobody-Group = nobody


      is there anything else I need to check to get this working?

      posted in Xen Orchestra
      N
      nasheayahu
    • Manually Mount A HD When Needed From XCP-ng?

      Can you manually mount a HD and I also have a Insignia Dual Drive Docking Station that I only want to mount a HD when I need it, specially when I want to do a backup and store the drive offline.

      The Docking Station is on and HD's are listed in Removable storage, so It that possible, if so can you link me the documentation to show me how?

      posted in Xen Orchestra docking station mount hd
