tjkreidl

@coolsport00 Sorry about the VMW need for the Cisco product. Sounds like you have a number of constraints, finances being I'm sure one of them! At least you have time on your hands and the means to experiment. You may, als, end up with a number of different platforms to meet your needs. We ran both Sun Microsystems and Red Hat Linux and Microsoft Windows servers, each taking on specific duties. It's far from ideal and probably not very cost-effective, but you do what you have to to get stuff to work.

tjkreidl

@coolsport00 While I was working at the university, we used RDS on Windows servers with RTX GPus with good results. The T4 I believe required NVIDIA licensing.
You have a few options: 1) Upgrade your servers if possible, 2) Add more hosts and GPUS (the used equipment market is one option, if you want to risk unsupported equipment),
3) If the GPU is the limitation and not the host, consider upgrading to a 5000 or 6000 series GPU. oOr NVIDIA GPUs to leverage the RTX vWS and CUDA capabilities, the latter's support being particularly important for Revit, AutoCaD, and other high-end graphics apps. We used P4 and T4 GPUs at the time with success under XenServer and with the high-end NVIDIA licensing (which unfortunately requires, as I'm sure you know, a separate VM running the licensing server).

In any case, you are fortunate to be able to test this all out way ahead of before you have to go live.

tjkreidl

@coolsport00 Why not then just do the GPU passthrough for the entire host and just put the VMs on that host that you want to leverage the GPU? To get specific vGPU capabilities, my recollection is that you'd need to use a GPU that most likely requires licensing, at least as far as NVIDIA is concerned.

tjkreidl

@coolsport00 See if any of this helps:

Here is the step-by-step guide to configure the NVIDIA GeForce RTX 3090 for full PCI passthrough to a virtual machine in XCP-ng.Step 1: Identify the GPU on the XCP-ng HostFirst, log in to your XCP-ng host via SSH or use the local console shell to find the exact hardware address of your RTX 3090.Run the following command to list your PCI devices and filter for NVIDIA:bashlspci | grep -i nvidia
Use code with caution.Look for the lines corresponding to your RTX 3090 and its Audio Controller. They will look similar to this:text01:00.0 VGA compatible controller: NVIDIA Corporation GA102 [GeForce RTX 3090] (rev a1)
01:00.1 Audio device: NVIDIA Corporation GA102 High Definition Audio Controller (rev a1)
Use code with caution.Take note of the PCI identifiers (e.g., 01:00.0 and 01:00.1). Note that your specific identifier numbers might vary based on your motherboard layout.Step 2: Hide the GPU from the Control Domain (Dom0)To prevent the main XCP-ng host system (Dom0) from seizing control of the graphics card, you must tell it to ignore those PCI IDs on boot.Instruct XCP-ng to assign the GPU components to the passthrough driver (xen-pciback) by executing this command (replace 01:00.0 and 01:00.1 with your actual IDs found in Step 1):bash/opt/xensource/libexec/xen-cmdline --set-dom0 "xen-pciback.hide=(01:00.0)(01:00.1)"
Use code with caution.Reboot the physical server for this driver isolation configuration to take effect:bashreboot
Use code with caution.Step 3: Verify the IsolationOnce your host boots back up, check that the hardware isolation worked as intended.Run this command to verify that the xen-pciback driver has correctly claimed the card:bashxl pci-assignable-list
Use code with caution.You should see your GPU addresses printed in the terminal, confirming they are ready to be passed into a virtual environment:text0000:01:00.0
0000:01:00.1
Use code with caution.Step 4: Attach the GPU to your VM
You can attach the isolated card either visually using Xen Orchestra (XO) or straight from the command line interface.Option A: Using Xen Orchestra (Recommended)Navigate to the Xen Orchestra management interface.Go to the VMs tab and click on the target virtual machine (ensure it is powered down).Click on the Advanced tab of that VM.Scroll down to the PCI devices block.Select both the RTX 3090 graphics and audio IDs from the dropdown checklist and save your changes.Option B: Using the Command Line (CLI)Find the unique identifier (UUID) of your VM:bashxe vm-list name-label="Your_VM_Name"
Use code with caution.Assign the GPU to that VM UUID using the following command syntax:bashxe vm-param-set uuid=<VM_UUID> other-config:pci=0/0000:01:00.0,0/0000:01:00.1
Use code with caution.Step 5: Boot and Install DriversPower on your virtual machine. You can now download and install the official desktop NVIDIA GeForce Drivers directly inside the guest operating system. The installer will recognize the device normally, and you do not need to register a license server or install vGPU client software.

AtaxyaNetwork

Hello everyone !

I rebuild a new OME appliance with the latest version (4.7)
What i did on the rebuild:

Via live CD
- add xen-blkfront and xen-netfront driver, and rebuild the initrd
- change root password
- activate SSH.
Via TUI
- Change admin password
- Set interface to DHCP
Via SSH

sed -i -e 's/sda/xvda/g' /opt/dell/omc/utilities/tui/bin/ome_disk_config.sh
sed -i -e 's/sda/xvda/g' /opt/dell/mcsi/appliance/scripts/appliance_resources.sh
bash /mnt/Linux/install.sh # To install XCP-ng tools

As usual, please send a DM if you want the link to the VHD

Also, if you want to build it yourself, the driver are here

Feedback is welcome !

(Disclamer: This build is something I create on my free time and to help people who have difficulty running Dell appliances on XCP-ng. I do not guarantee a fully functional appliance, but I do my best to make it work. If you have a support contract with Dell and require official support for OME, please contact Dell and request compatibility with XCP-ng.)
