XOA - Memory Usage

[florent]

we merge the code into master ( including the code to allow a heap memory export )

[MajorP93]

@florent Thanks!
I did not have time (yet) to look into the heap export due to weekend being in between.
I will update to current master and provide you with the heap export in the following days.
Best regards

[florent]

@MajorP93 said:

@florent Thanks!
I did not have time (yet) to look into the heap export due to weekend being in between.
I will update to current master and provide you with the heap export in the following days.
Best regards

no problem , the sooner we'll have these exports, the sooner we will be able to indentify what is leaking in your usage, since we already plugged the leaks we reproduced in our labs

[MajorP93]

@florent Unfortunately Xen Orchestra RAM usage issue is back on my end.
During delta backups everything looked quite good but yesterday full backups were due according to our schedule.
The initial full backup succeeded but during the mirror job that is being started by sequence after the delta job finished the RAM issue got triggered.
We are using SMB backup remotes by the way.

XO VM has 10GB RAM in total plenty of which is free during backups. Still XO backup failed due to ENOMEM.

I can see in dmesg output on the Xen Orchestra VM:

[71584.204045] kworker/u37:2: page allocation failure: order:4, mode:0x40d40(GFP_NOFS|__GFP_ZERO|__GFP_COMP), nodemask=(null),cpuset=/,mems_allowed=0
[71584.204069] CPU: 4 UID: 0 PID: 75928 Comm: kworker/u37:2 Not tainted 6.18.25 #1 PREEMPT(lazy)
[71584.204075] Hardware name: Xen HVM domU, BIOS 4.17 04/21/2026
[71584.204077] Workqueue: writeback wb_workfn (flush-cifs-2)
[71584.204087] Call Trace:
[71584.204091]  <TASK>
[71584.204096]  dump_stack_lvl+0x61/0x80
[71584.204103]  warn_alloc+0x151/0x1c0
[71584.204109]  ? psi_memstall_leave+0x83/0xa0
[71584.204116]  __alloc_pages_slowpath+0xdf2/0xe90
[71584.204124]  __alloc_frozen_pages_noprof+0x2bb/0x350
[71584.204129]  alloc_pages_mpol+0x107/0x190
[71584.204135]  ___kmalloc_large_node+0x46/0x100
[71584.204140]  __kmalloc_large_node_noprof+0x1d/0xd0
[71584.204144]  __kmalloc_noprof+0x358/0x5e0
[71584.204150]  ? crypt_message+0x50b/0x940 [cifs]
[71584.204259]  crypt_message+0x50b/0x940 [cifs]
[71584.204365]  smb3_init_transform_rq+0x278/0x310 [cifs]
[71584.204458]  smb_send_rqst+0x120/0x1c0 [cifs]
[71584.204551]  cifs_call_async+0x2b8/0x370 [cifs]
[71584.204632]  ? __pfx_smb2_writev_callback+0x10/0x10 [cifs]
[71584.204714]  smb2_async_writev+0x405/0x600 [cifs]
[71584.204800]  netfs_advance_write+0xcd/0xf0 [netfs]
[71584.204827]  netfs_write_folio+0x509/0x7c0 [netfs]
[71584.204850]  netfs_writepages+0x28f/0x440 [netfs]
[71584.204872]  do_writepages+0xdc/0x1f0
[71584.204878]  ? update_curr+0x2f/0x180
[71584.204884]  __writeback_single_inode+0x3e/0x320
[71584.204889]  writeback_sb_inodes+0x274/0x4a0
[71584.204901]  __writeback_inodes_wb+0x9a/0xf0
[71584.204906]  wb_writeback+0x15b/0x300
[71584.204913]  wb_workfn+0x3af/0x590
[71584.204918]  process_scheduled_works+0x1d7/0x420
[71584.204923]  worker_thread+0x21a/0x2f0
[71584.204927]  ? __pfx_worker_thread+0x10/0x10
[71584.204930]  kthread+0x201/0x260
[71584.204937]  ? __pfx_kthread+0x10/0x10
[71584.204941]  ret_from_fork+0x107/0x210
[71584.204946]  ? __pfx_kthread+0x10/0x10
[71584.204950]  ret_from_fork_asm+0x1a/0x30
[71584.204956]  </TASK>
[71584.205026] Mem-Info:
[71584.205031] active_anon:288751 inactive_anon:14365 isolated_anon:0
                active_file:1227362 inactive_file:783958 isolated_file:0
                unevictable:768 dirty:32364 writeback:1024
                slab_reclaimable:113003 slab_unreclaimable:26821
                mapped:47649 shmem:936 pagetables:6024
                sec_pagetables:0 bounce:0
                kernel_misc_reclaimable:0
                free:40796 free_pcp:5103 free_cma:0
[71584.205041] Node 0 active_anon:1155004kB inactive_anon:57460kB active_file:4909448kB inactive_file:3135832kB unevictable:3072kB isolated(anon):0kB isolated(file):0kB mapped:190596kB dirty:129456kB writeback:4096kB shmem:3744kB shmem_thp:0kB shmem_pmdmapped:0kB anon_thp:522240kB kernel_stack:7600kB pagetables:24096kB sec_pagetables:0kB all_unreclaimable? no Balloon:0kB
[71584.205050] Node 0 DMA free:13312kB boost:0kB min:100kB low:124kB high:148kB reserved_highatomic:0KB free_highatomic:0KB active_anon:0kB inactive_anon:0kB active_file:0kB inactive_file:0kB unevictable:0kB writepending:0kB zspages:0kB present:15996kB managed:15360kB mlocked:0kB bounce:0kB free_pcp:0kB local_pcp:0kB free_cma:0kB
[71584.205060] lowmem_reserve[]: 0 3720 9925 9925 9925
[71584.205068] Node 0 DMA32 free:108944kB boost:0kB min:25084kB low:31352kB high:37620kB reserved_highatomic:0KB free_highatomic:0KB active_anon:527548kB inactive_anon:0kB active_file:73972kB inactive_file:2908844kB unevictable:0kB writepending:133552kB zspages:0kB present:3915188kB managed:3809364kB mlocked:0kB bounce:0kB free_pcp:16856kB local_pcp:3944kB free_cma:0kB
[71584.205078] lowmem_reserve[]: 0 0 6205 6205 6205
[71584.205085] Node 0 Normal free:43900kB boost:0kB min:42392kB low:52988kB high:63584kB reserved_highatomic:2048KB free_highatomic:2048KB active_anon:627456kB inactive_anon:57460kB active_file:4835476kB inactive_file:226988kB unevictable:3072kB writepending:0kB zspages:0kB present:6545408kB managed:6353952kB mlocked:0kB bounce:0kB free_pcp:664kB local_pcp:248kB free_cma:0kB
[71584.205094] lowmem_reserve[]: 0 0 0 0 0
[71584.205101] Node 0 DMA: 0*4kB 0*8kB 0*16kB 0*32kB 0*64kB 0*128kB 0*256kB 0*512kB 1*1024kB (U) 2*2048kB (UM) 2*4096kB (M) = 13312kB
[71584.205120] Node 0 DMA32: 1553*4kB (UME) 1096*8kB (UME) 822*16kB (UME) 671*32kB (UM) 236*64kB (UM) 104*128kB (UM) 34*256kB (UM) 2*512kB (UM) 3*1024kB (M) 7*2048kB (M) 2*4096kB (M) = 113348kB
[71584.205194] Node 0 Normal: 71*4kB (UME) 998*8kB (UM) 1524*16kB (UE) 280*32kB (UE) 11*64kB (UE) 0*128kB 0*256kB 0*512kB 0*1024kB 1*2048kB (H) 0*4096kB = 44364kB
[71584.205216] Node 0 hugepages_total=0 hugepages_free=0 hugepages_surp=0 hugepages_size=1048576kB
[71584.205219] Node 0 hugepages_total=0 hugepages_free=0 hugepages_surp=0 hugepages_size=2048kB
[71584.205221] 2012251 total pagecache pages
[71584.205223] 2 pages in swap cache
[71584.205225] Free swap  = 7294960kB
[71584.205226] Total swap = 7294968kB
[71584.205228] 2619148 pages RAM
[71584.205229] 0 pages HighMem/MovableOnly
[71584.205231] 74479 pages reserved
[71584.205232] 0 pages hwpoisoned

My XO from sources instance is running 6.4.0 release commit.

Best regards

//EDIT: maybe the issue that I am experiencing from time to time is being related to SMB remote?
Maybe backups to SMB remote are using different code path than e.g. NFS?

[acebmxer]

@MajorP93

Not seeing any issues on my end. I only have NFS SRs or Remotes. No SMBs.

home lab

Work XOA - just updated XOA, proxies, and host last night after backup jobs.... Just told @florent he could close my open support ticket. Maybe i jumped the gun....

[olivierlambert]

SMB can be the culprit, not in XO directly but could trigger different things; That would be interesting to see if you can reproduce the issue on NFS.

[florent]

@acebmxer
If you are ok, you can do a heap memory export ( not that you will probably have to restart the xoa after to free the memory)

If you can do it, and we will collect the memory file on monday ( or when you are ready) , and see if this is a new cause or the return of an old one

[acebmxer]

@florent

I didnt setup ssh on work XOA i just set the password but need to reboot it for it to work. The tunnel is still open if you dont mind doing it otherwise I will need to reboot xoa to get in myself.

[florent]

@acebmxer said:

@florent

I didnt setup ssh on work XOA i just set the password but need to reboot it for it to work. The tunnel is still open if you dont mind doing it otherwise I will need to reboot xoa to get in myself.

I can do it on monday

[acebmxer]

@florent

Just checking to make sure you got the memory dump?
